| Amplification |
Amplifier Design |
Direct Energy |
|
Power Output: Watts per Channel |
80 W/ch (8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven, FTC), 170 W/ch (6 ohms, 1 kHz, THD 10 %, 1ch Driven) |
|
Channels |
7 |
|
Power Output: Watts per Channel (1kHz,10%THD@6ohm 1ch Driven) |
165 W/ch |
| Audio Features |
Dolby Atmos®, Dolby Surround Upmixer |
✓ |
|
DTS:X®, DTS Neural:X® Upmixer |
✓ |
|
Reflex Optimizer |
✓ |
|
Dolby Atmos Height Virtualizer |
✓ |
|
DTS Virtual: X |
✓ |
|
Dolby® TrueHD, Dolby Digital Plus |
✓ |
|
DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS-HD Express |
✓ |
|
DSD Disc (SACD) Playback via HDMI (2.8 MHz/2ch, 5.1ch) |
✓ |
|
Digital Quad-Core 32-bit DSP (Cirrus Logic) |
✓ |
|
192 kHz/24-bit D/A Conversion for Hi-Res Audio |
✓ |
|
Enhanced Audio Return Channel (eARC) on HDMI OUT (MAIN) |
✓ |
|
MCACC Auto Room Tuning |
Phase Control | Subwoofer EQ |
|
Advanced Sound Retriever (2ch) |
✓ |
|
Advanced Surround Modes |
Classical, Unplugged, Entertainment Show, Drama, Advanced Game, Action, Rock/Pop, Sports, Extended Stereo, Mono Music, Front Stage Surround Advance |
| Video Features |
Support HDMI 2.1 |
(HDMI IN 1-3) with 8K, VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), QFT (Quick Frame transport), DSC (Display Stream Compression), and QMS (Quick Media Switching) pass-through |
|
Supports HDR10+, HDR10, and HLG |
8K/60p (4:2:0/10-bit), 8K/30p (4:4:4/10-bit, 4:2:2/12-bit), 4K/120p (4:4:4/10-bit, 4:2:2/12-bit), 4K60p (4:4:4/12-bit) and BT.2020 color; Deep Color™ (36-bit), "x.v.Color", LipSync, and HDCP 2.3 |
|
Dolby Vision Compatible |
✓ |
|
Ultra HD Upscaling |
4K to 8K, 1080p to 8K/4K |
| Home Network Features |
Works with Alexa supporting multi-room music |
✓ |
|
Works with Hey Google and Chromecast built-in |
✓ |
|
DTS Play-Fi® supporting Critical Listening mode with Pioneer Music Control App |
✓ |
|
Apple AirPlay 2 with Siri Voice Control |
✓ |
|
Works with SONOS supporting multiple Sonos Connect control and Volume Pass Through mode |
✓ |
|
Amazon Music HD, Pandora®, Spotify, TIDAL, and Deezer Hi-Fi Music-Streaming Services Ready |
✓ |
|
Internet Radio with TuneIn |
✓ |
|
Hi-Res Audio File Playback via USB/Network |
✓ |
|
Up to 192 kHz/24-bit ALAC*5, AIFF, FLAC, WAV (RIFF) and 5.6 MHz DSD |
✓ |
| Convenience Features |
Personal Preset |
✓ |
|
Dialog Enhancement |
✓ |
|
Dual Band (5 GHz/2.4 GHz) Wi-Fi® Built-in |
✓ |
|
Bluetooth® Wireless Technology |
Version: 4.2, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/aptX/aptX HD (TX), SBC/AAC (RX) Built-in |
|
Pioneer Remote App |
Ready for Multi-room Entertainment Control and Network Streaming |
|
User-Friendly GUI with System Setup Menu |
✓ |
|
On-Screen Information for Audio, Video and Network |
✓ |
|
Web Setup |
✓ |
|
Auto Power Off in HDMI Standby Through |
✓ |
|
FM/AM Tuner 40 Presets |
✓ |
|
User-Friendly Simple Remote Control |
✓ |
| Font Terminals |
USB 1 In for USB Drive |
✓ |
|
MCACC Setup MIC In |
✓ |
|
Audio 1 In (Mini Stereo Jack) |
✓ |
|
Phones 1 Out |
✓ |
| Video Processing |
4K Ultra HD Pass-Through |
Yes (HDR10, HLG and BT.2020 Wide Color Gamut Signal Pass-through) |
|
3-D Ready |
Yes |
|
HDMI Standby Through |
Yes with Input Switch / Last Memory |
|
HDMI 36-bit Deep Color |
Yes |
|
Video Processor |
- |
|
Component Video Scaler |
- |
|
Pure Cinema I/P Converter |
- |
|
3D Noise Reduction |
- |
|
4K Ultra HD Video Scaler |
Ultra HD Upscaling |
|
Audio Return Channel |
Yes |
|
Dolby Vision Compatible |
Yes |
|
HDMI x.v. Color |
Yes |
|
Video Converter to HDMI |
Yes |
|
Composite Video Scaler |
- |
|
Advanced Video Adjustment |
- |
|
Super Resolution |
Yes |
| Connectivity |
HDMI Input / Output |
6 In (Rear) / 2 Out |
|
Wi-Fi Built-In |
Dual Band (5 GHz/2.4 GHz) Wi-Fi® Built-in |
|
Wireless Adapter Port |
- |
|
Component Video Input / Output |
- |
|
iPhone / iPod / USB Memory Input |
- |
|
Ethernet Input |
- |
|
Digital Audio Inputs / Output |
2 In (Optical 1, Coaxial 1) |
|
Headphone Output |
Yes |
|
AM/FM Presets |
AM/FM Tuner 40 Presets |
|
MHL 2 |
- |
|
Bluetooth Built-In |
Yes (Version: 4.2 + LE, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/AAC) |
|
Bluetooth Adapter Port |
- |
|
Composite A/V Input / Output |
- |
|
USB Terminal |
Front and Rear |
|
Analog Audio Inputs / Output |
2 in / 0 out |
|
Pre-Amp Output |
0.2 ch. |
|
Front A/V Inputs |
USB / 3.5mm stereo mini jack |
| Installation |
On-Screen Display |
User-Friendly GUI with System Setup Menu |
|
Multi-Room and Source Output |
Powered Zone 2 with Dedicated DAC |
|
Multi-Zone On-Screen Display |
- |
|
Function Rename |
- |
|
Sleep Timer |
Yes |
|
Auto Power Down |
Yes |
|
IR Serial Remote In/Out |
- |
|
FL Dimmer |
- |
|
Remote |
Yes |
|
Versatile Speaker Configuration |
Speaker 9ch Out (FRONT, CENTER,SURROUND, SURROUND BACK/HEIGHT/Bi-AMP, ZONE 2) |
| Contruction |
Front Panel |
Brushed |
|
Speaker Terminals |
9 large |
| Dimensions |
W x H x D (inches) Wi-Fi Antenna's Up |
- |
|
Weight |
20.7 lbs. |
|
W x H x D (inches) |
17-1/8 x 6-13/16 x 14-9/16 |
| 原產地 |
|
馬來西亞 |
